Smart wifi relay for home automation – Shelly Plus 1

80.00 د.إ inc. VAT

Category Tag

WiFi-operated smart switch, 1 channel 16A

Control a wide range of home appliances and office equipment (lights, power lines, security systems, heaters, radiators, sockets, LED strips, etc.) from anywhere.

  • Dry contacts
  • Extremely fast processor – ESP32, Improved API interface
  • Enhanced safety
  • Enhanced security – MQTT and WSS support, TLS and custom certificates support
  • Designed to fit in most standard electrical boxes and switches
  • Easy control through the Shelly app, various protocols, and platforms, as well as voice assistants

Standard warranty(included in purchase price):

12 month warranty due to device malfunctions.

Specifications

Type Value
Physical
Size (HxWxD): 37x42x16 ±0.5 mm / 1.46×1.65×0.63 ±0.02 in
Weight: 26 g / 0.92 oz
Mounting: Wall console
Screw terminals max torque: 0.4 Nm / 3.5 lbin
Conductor cross section: 0.5 to 1.5 mm² / 20 to 16 AWG
Conductor stripped length: 5 to 6 mm / 0.20 to 0.24 in
Shell material: Plastic
Color: Blue
Environmental
Ambient temperature: -20 °C to 40 °C / -5 °F to 105 °F
Humidity 30 % to 70 % RH
Max. altitude 2000 m / 6562 ft
Electrical
Power supply: 110 – 240 VAC / 24 – 48 VDC / 12 VDC ±10%
Power consumption: < 1.2 W
Output circuits ratings
Max switching voltage AC: 240 V
Max switching voltage DC: 30 V
Max switching current AC: 16 A
Max switching current DC: 10 A
Sensors, meters
Internal-temperature sensor: Yes
Radio
RF band: 2400 – 2495 MHz
Max. RF power: <20 dBm
Wi-Fi protocol: 802.11 b/g/n
Wi-Fi Range: Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors
(Depends on local conditions)
Bluetooth Protocol: 4.2
Bluetooth Range: Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors
(Depends on local conditions)
MCU
CPU: ESP32
Flash: 4 MB
Firmware capabilities
Schedules: 20
Webhooks (URL actions): 20 with 5 URLs per hook
Scripting: Yes
MQTT: Yes
CoAP: No

Download



Shelly 1 user guide

Installation Video

Shelly Plus 1 Installation Video
